fiber optik patch kablosu

Single Mode Fiber Optic Patch Cord with APC ≥60dB UPC ≥50dB and PC ≥45dB Return Loss for FTTH CATV Telecom

Tüm Kategori

Anahtar ve soket

Bizimle İletişim

Mrs. Alice

sales03@newlightfiber.com

0086-13534063703

0086 13534063703

Şimdi iletişime geçin

Single Mode Fiber Optic Patch Cord with APC ≥60dB UPC ≥50dB and PC ≥45dB Return Loss for FTTH CATV Telecom

Marka Adı:	WNRLN
Model Numarası:	OS2-POL-SM-002
Moq:	10 adet
fiyat:	USD 0.80-7.50 / Piece
Paketleme Ayrıntıları:	Toz kapaklı bireysel PE torba, WNRLN markalı kutu, ihracata uygun oluklu karton
Ödeme Şartları:	T/T,L/C,PayPal,Western Union

Ayrıntılı Bilgiler

Ürün Tanımı

Ayrıntılı Bilgiler

Menşe yeri:

Guangdong, Çin

Sertifika:

ISO 9001:2015, RoHS, CE, TIA/EIA-568-C.3

Elyaf türü:

OS2 Tek Mod (G652D / G657A1 / G657A2)

Konektör Türleri:

SC, LC, FC, ST, E2000

Lehçe Türü:

UPC / APC / PC

Ekleme Kaybı (UPC):

≤0,20dB Tipik, ≤0,30dB Maks

Ekleme Kaybı (APC):

≤0,20dB Tipik, ≤0,30dB Maks

Geri Dönüş Kaybı (UPC):

≥50dB

Geri Dönüş Kaybı (APC):

≥60dB

Geri Dönüş Kaybı (PC):

≥45dB

Kablo çapı:

0,9 mm / 2,0 mm / 3,0 mm

Ceket Malzemesi:

PVC / LSZH / OFNP / OFNR

Yüksük malzemesi:

Zirkonya seramik

Çalışma Dalga Boyu:

1310nm / 1550nm

Çalışma Sıcaklığı:

-40 ° C ila +75 ° C

Yetenek temini:

Ayda 100000 adet

Vurgulamak:

UPC APC PC Polish Patch Cord

Single Mode OS2 SC LC Connector

High Return Loss FTTH CATV Jumper

Ürün Tanımı

UPC/APC/PC Polish Single Mode Fiber Optic Patch Cord

Polish Types & Specifications

🟢

APC Polish (8° Angled)

≥60dB return loss with 8° angled end-face. Green connector body. The industry standard for CATV, RF over fiber, and FTTx PON networks where back reflection must be minimal.

🔵

UPC Polish (Ultra Physical Contact)

≥50dB return loss with domed end-face. Blue connector body. Ideal for telecom backbone, data center, and enterprise networks requiring stable low-loss connections.

⚫

PC Polish (Physical Contact)

≥45dB return loss with slightly domed end-face. Cost-effective solution for legacy installations and applications where ultra-high return loss is not critical.

Polish Type Comparison

Parameter	PC Polish	UPC Polish	APC Polish
End-Face Geometry	Slight Dome	Extended Dome	8° Angled
Return Loss	≥45dB	≥50dB	≥60dB
Insertion Loss (Typical)	≤0.30dB	≤0.20dB	≤0.20dB
Connector Body Color	Black / Beige	Blue	Green
Best Application	Legacy Systems	Telecom / Data Center	CATV / FTTx / RF

Technical Specifications

Fiber Type: OS2 Single Mode (G652D / G657A1 / G657A2)

Connector Types: SC, LC, FC, ST, E2000

Polish Options: UPC / APC / PC

Core Count: Simplex / Duplex

Cable Diameter: 0.9mm / 2.0mm / 3.0mm

Jacket Material: PVC / LSZH / OFNP / OFNR

Operating Wavelength: 1310nm / 1550nm

Operating Temperature: -40°C to +75°C

Ferrule Material: Premium Zirconia Ceramic

Test Standard: 100% OTDR Tested, IEC 61300-3-6 Compliant

Applications by Polish Type

APC — CATV & RF Over Fiber

FTTH PON, HFC networks, analog video transport, GPON/EPON OLT to ONU links

UPC — Telecom & Data Center

DWDM systems, SDH/SONET backbone, SAN fabric, enterprise structured cabling

PC — Legacy Installations

Existing multimode networks, test equipment connections, non-critical monitoring systems

Quality Assurance & Factory Direct Supply

Every patch cord undergoes 100% OTDR testing and end-face 3D interferometry inspection. Custom polish type, connector combination, and cable length available. Contact us for OEM/ODM inquiries and bulk wholesale pricing.

100% OTDR Tested 3D Interferometry ISO 9001 Factory Custom OEM/ODM
